MOLEX 1510481401 CP-6.5 Header
The MOLEX 1510481401 is a CP-6.5 header within the 151048 series, engineered for robust wire-to-board connectivity. It boasts a 6.50mm pitch, a dual-row design, and a vertical orientation, offering a compact and efficient solution. Key features include polarization and a positive lock mechanism for secure mating. Constructed with a copper alloy and polyamide resin, and finished with matte tin plating, this header provides excellent durability and electrical performance. It is ideal for applications in various industries requiring reliable and high-performance wire-to-board connections.
MOLEX 1510481401 CP-6.5 Header Specifications:
- overview: CP-6.5 Wire-to-Board Connector System
- product_family: PCB Headers
- application: Wire-to-Board
- comments: See Product Specification for maximum current rating by circuit size and wire AWG
- upc: 889056066716
- circuits_loaded: 4
- circuits_maximum: 4
- color_resin: Blue
- durability_mating_cycles: 30
- first_mate_last_break: No
- flammability: 94V-0
- glow_wire_compliant: No
- guide_to_mating_part: Yes
- lock_to_mating_part: Yes
- material_metal: Copper Alloy
- material_plating_mating: Matte Tin
- material_plating_termination: Matte Tin
- material_resin: Polyamide
- net_weight_g: 2.884
- number_of_rows: 2
- orientation: Vertical
- pc_tail_length_mm: 3.80
- pcb_locator: Yes
- pcb_retention: Yes
- pcb_thickness_recommended_mm: 1.60
- packaging_type: Tray
- pitch_mating_interface_mm: 6.50
- plating_min_mating_um: 1.270
- plating_min_termination_um: 1.270
- polarized_to_mating_part: Yes
- polarized_to_pcb: Yes
- temperature_range_operating_c: -40°C to +105°C
- termination_interface_style: Through Hole
- current_maximum_per_contact_a: 10.0
- voltage_maximum_v: 600
- lead_free_process_capability: WAVE
