MOLEX 151660211 Premo-Flex FFC Jumper
The MOLEX 15166-0211 Premo-Flex FFC Jumper is a flexible flat cable connector designed for applications requiring a compact and reliable connection. With a 0.50mm pitch and 20 circuits, this jumper offers a fine-pitch solution for connecting flexible circuits. The tin plating provides excellent solderability and corrosion resistance. It is commonly used in consumer electronics, industrial equipment, and automotive applications where space is limited and flexibility is required.
MOLEX 151660211 Premo-Flex FFC Jumper Specifications:
- Overview: Premo-Flex Cable Jumpers
- Description: 0.50mm Pitch Premo-Flex FFC Jumper, Same Side Contacts (Type A), 102.00mm Cable Length, Tin (Sn) Plating, 20 Circuits
- Cable Length: 102.00mm
- Circuits (Loaded): 20
- Material - Plating Mating: Tin
- Net Weight: 1.000/g
- Packaging Type: Bag
- Pitch - Mating Interface: 0.50mm
- Temperature Range - Operating: -40° to +105°C
- Current - Maximum per Contact: 0.5A
- Voltage - Maximum: 60V AC
- UPC: 884982847033
- EU ELV: Not Relevant
- EU RoHS: Compliant
- REACH SVHC: Not Contained
- Halogen-Free Status: Not Low-Halogen
- RoHS Phthalates: Not Contained
- Mates With: Easy-On FFC/FPC Connector: 527452033, 527462033, 525592033, 525592034
Buy the 15166-0211 MOLEX Premo-Flex FFC Jumper | myMectronic
Purchase the MOLEX 15166-0211 Premo-Flex FFC Jumper securely and reliably online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 151660211?
You can click on the BUY or RFQ button to purchase 151660211 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 151660211?
You can download the 151660211 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 151660211?
MOLEX
