MOLEX 15912040 C-Grid Connector
The 2.54mm pitch C-Grid header is a surface-mount, dual-row connector designed for board-to-board applications. Made from phosphor bronze with tin plating, it features 4 circuits in a vertical orientation, is resistant to 25 mating cycles, and is suitable for high-temperature environments up to +105°C. Certified by CSA and UL, it offers reliable electrical performance with a maximum current of 3.0A per contact and a voltage rating of 250V. Its black high-temperature thermoplastic housing enhances durability and compatibility with reflow soldering processes, making it ideal for compact electronic assemblies.
MOLEX 15912040 C-Grid Connector Specifications:
- Pitch - Mating Interface: 2.54mm
- Number of Rows: 2
- Circuits (Loaded): 4
- Circuits (maximum): 4
- Color - Resin: Black
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: High Temperature Thermoplastic
- Durability (mating cycles max): 25
- Temperature Range - Operating: -40° to +105°C
- Current - Maximum per Contact: 3.0A
- Voltage - Maximum: 250V
- Flammability: 94V-0
- Packaging Type: Bag
Buy the Molex Series C-Grid Signal Connector: 0015912040
Order the Molex C-Grid Connector with 2.54mm pitch and four circuits today. Designed for durability and high-performance in surface-mount applications, it features tin plating, UL and CSA certification, and operates reliably between -40°C and +105°C. Its compact design is perfect for densely populated electronic assemblies, providing secure connections with up to 25 mating cycles. Trusted by professionals, this connector ensures excellent electrical performance, making it a vital component for reliable electronic device development and manufacturing.
Get Molex 15912040 today—built for precision and long-lasting durability in electronic connections.
Frequently Asked Questions
Where can I buy MOLEX 15912040?
You can click on the BUY or RFQ button to purchase 15912040 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 15912040?
You can download the 15912040 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 15912040?
MOLEX
