MOLEX 15913060 C-Grid Connector
The 2.54mm Pitch C-Grid Header is a surface-mount, dual-row connector designed for board-to-board and signal wiring applications. Made of phosphor bronze with gold plating, it features a vertical orientation, 6 circuits, and a high-temperature thermoplastic housing. Suitable for high-density electronic assemblies, it offers reliable electrical performance with a maximum current of 3.0A per contact and voltage of 250V. RoHS and REACH compliant, it supports up to 50 mating cycles and operates between -40°C to +105°C, ensuring durability in demanding environments.
MOLEX 15913060 C-Grid Connector Specifications:
- Pitch: 2.54mm
- Number of Circuits: 6
- Color - Resin: Black
- Material - Metal: Phosphor Bronze
- Plating Mating: Gold
- Plating Termination: Tin
- Material - Resin: High Temperature Thermoplastic
- Durability (mating cycles max): 50
- Flammability: 94V-0
- Operating Temperature Range: -40°C to +105°C
- Current - Maximum per Contact: 3.0A
- Voltage - Maximum: 250V
- Solder Process: Reflow with max temperature 260°C, duration 30 seconds
- Net Weight: 0.364 grams
Buy the Molex Series 71308 C-Grid Connector: 15913060
Purchase the Molex Series 71308 C-Grid Header online today to benefit from its reliable 2.54mm pitch, 6 circuits, and gold-plated contacts. Designed for surface-mount applications, this dual-row connector offers high durability with up to 50 mating cycles and operates effectively within a temperature range of -40°C to +105°C. Made of high-temperature thermoplastic and phosphor bronze, it ensures excellent electrical performance and robustness in demanding environments. Order now to secure your high-quality electronic connection solution with fast online delivery.
Order your Molex Series 71308 C-Grid Header with 6 circuits today and ensure reliable, high-quality electronic connections for your projects.
Frequently Asked Questions
Where can I buy MOLEX 15913060?
You can click on the BUY or RFQ button to purchase 15913060 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 15913060?
You can download the 15913060 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 15913060?
MOLEX
