MOLEX 1716920202 Mega-Fit Receptacle Housing
The MOLEX 171692-0202 is a Mega-Fit receptacle housing, part of the 171692 series, engineered for robust power connections in various applications including wire-to-board and wire-to-wire systems. This housing is characterized by its dual-row design, accommodating 2 circuits, and is manufactured with UL 94V-0 rated nylon resin for improved fire safety. It is glow-wire capable and polarized to the mating part, ensuring proper alignment. The housing is compatible with Mega-Fit headers and terminals, offering a comprehensive solution for power distribution and signal transmission in industrial and commercial settings.
MOLEX 1716920202 Mega-Fit Receptacle Housing Specifications:
- circuit_maximum: 2
- color_resin: Black
- gender: Receptacle
- glow_wire_capable: Yes
- keying_to_mating_part: None
- lock_to_mating_part: Yes
- material_resin: Nylon
- net_weight: 1.680 g
- number_of_rows: 2
- packaging_type: Bag
- panel_mount: No
- pitch_mating_interface: 5.70 mm
- pitch_termination_interface: 5.70 mm
- polarized_to_mating_part: Yes
- stackable: No
- temperature_range_operating: -40° to +105°C, -40° to +120°C
- elv_compliance: Not Relevant
- rohs_compliance: Compliant
- reach_svhc_compliance: Not Contained Per ED/88/2018
- halogen_free_status: Not Low-Halogen
- rohs_phthalates_compliance: Not Contained
- series: 171692
- mates_with: Mega-Fit Headers 76825, 76829, 172065, 172064, Mega-Fit Plug Housing 105411
- use_with: Mega-Fit TPA 105415, Mega-Fit Crimp Terminals 76823, 172063
Buy the 171692-0202 MOLEX Mega-Fit Receptacle Housing | myMectronic
Purchase the genuine MOLEX 171692-0202 Mega-Fit Receptacle Housing securely and reliably online.
