MOLEX 1718561003 KK 254 RPC Vertical Header
The MOLEX 171856-1003 is a KK 254 RPC Vertical Header, part of the KK Interconnect System. This header is designed for applications requiring a 2.54mm pitch and features a friction lock mechanism for secure mating. It boasts a gold plating on the mating interface and matte tin plating on the termination, ensuring excellent electrical conductivity and solderability. Suitable for board-to-board, power, signal, and wire-to-board applications, this header is ideal for a range of industrial and commercial electronics projects. Refer to the product specification for detailed current rating and operating temperature range information.
MOLEX 1718561003 KK 254 RPC Vertical Header Specifications:
- Pitch - Mating Interface: 2.54mm
- Circuits (Loaded): 3
- Circuits (maximum): 3
- Plating min - Mating: 0.381µm
- Plating min - Termination: 2.540µm
- Material - Plating Mating: Gold
- Material - Plating Termination: Matte Tin
- Material - Resin: High Temperature Thermoplastic
- PCB Thickness - Recommended: 1.60mm
- Temperature Range - Operating: -40° to +105°C, -40° to +80°C
- Current - Maximum per Contact: 4.0A
- Voltage - Maximum: 500V
- Flammability: 94V-1
- Durability (mating cycles max): 25
- Number of Rows: 1
- Orientation: Vertical
- Mates With: 4455, 2695, 6471
