MOLEX 19092151 Pin and Socket Plug Housing
The MOLEX 19-09-2151 is a robust pin and socket plug housing within the 1991 series. Designed for wire-to-wire applications, it boasts a 2.36mm diameter and incorporates a positive latch mechanism for reliable connection. With 15 circuits arranged in 3 rows, this housing is polarized to ensure correct mating. It's constructed from Nylon resin, offering good durability and a temperature operating range of -40°C to +105°C. The housing is RoHS compliant and suitable for applications where halogen content needs to be minimized.
MOLEX 19092151 Pin and Socket Plug Housing Specifications:
- diameter: 2.36mm
- circuits_max: 15
- rows: 3
- latch: Positive
- polarity: Polarized to Mating Part
- material: Nylon
- operating_temp_range: -40° to +105°C
- current_max_per_contact: 7.5A
- flammability: 94V-2
- weight: 9.352/g
- pitch_mating_interface: 6.30mm
- stackable: No
- halogen_free_status: Low-Halogen
- reach_svhc: Not Contained
- glow_wire_capable: No
- keying_to_mating_part: None
- lock_to_mating_part: Yes
- breakaway: No
