MOLEX 2002411213 Mega-Fit Power Connector
The MOLEX 200241-1213 is a Mega-Fit Power Connector, a right-angle header designed for robust wire-to-board connections. With a 5.70mm pitch and 3 circuits, this connector is ideal for power applications requiring a compact and reliable solution. The matte tin plating ensures excellent solderability and corrosion resistance. It is constructed with a high-conductivity copper base, liquid crystal polymer resin, and is glow-wire capable, meeting stringent safety standards. This connector is RoHS compliant and designed for ease of use in various industrial and commercial applications.
MOLEX 2002411213 Mega-Fit Power Connector Specifications:
- Product Family: Mega-Fit Power Connectors
- Application: Power, Wire-to-Board
- Current-Max: 23.5A
- Datasheet Order No: 987650-5401
- Pitch-Mating: 5.70mm
- Product Name: Mega-Fit
- Circuits (maximum): 3
- Color - Resin: Black
- Durability (mating cycles max): 20
- Glow-Wire Capable: Yes
- Guide to Mating: No
- Keying to Mating Part: No
- Lock to Mating Part: No
- Material - Metal: High Conductivity Copper
- Material - Plating: Matte Tin
- Mating Material - Plating: Matte Tin
- Material - Resin: Liquid Crystal Polymer
- Net Weight: 2.260/g
- Orientation: Right Angle
- PC Tail Length: 3.60mm
- PCB Locator: No
- PCB Retention: Yes
- PCB Thickness - Recommended: 1.58mm, 2.36mm
- Packaging Type: Tray
- Pitch - Termination: 5.70mm
- Plating min - Mating: 1.524µm
- Plating min - Termination: 2.540µm
- Polarized to Mating Part: Yes
- Polarized to PCB: Yes
- Temperature Range - Operating: -40° to +105°C, -40° to +120°C
- Termination Interface: Style: Through Hole
- Voltage - Maximum: 600V AC (RMS)/DC
Buy the 200241-1213 MOLEX Mega-Fit Power Connector | myMectronic
Purchase the MOLEX 200241-1213 Mega-Fit Power Connector securely and conveniently online.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 2002411213?
You can click on the BUY or RFQ button to purchase 2002411213 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2002411213?
You can download the 2002411213 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2002411213?
MOLEX
