MOLEX 2070170010 Power Connector Housing
The Mini-Fit Sigma Sealed Plug Housing in a dual-row configuration features a 4.20mm pitch with 10 circuits, ideal for power applications requiring durability and reliability. Made from flame-retardant nylon, it offers excellent resistance to heat from -40°C to +105°C, and is UL94V-0 rated for safety. This sealed connector housing ensures protection against moisture and contaminants, suitable for wire-to-board and wire-to-wire connections. It is compatible with Mini-Fit Jr. receptacles and accessories, making it versatile for various industrial, automotive, and electronic power systems requiring secure and robust connections.
MOLEX 2070170010 Power Connector Housing Specifications:
- Series: Mini-Fit Family Power Connectors
- Number of Circuits: 10
- Color: Natural
- Material: Nylon
- Flammability Rating: UL94V-0
- Pitch: 4.20mm
- Temperature Range: -40°C to +105°C
- Gender: Plug
- Lock to Mating Part: No
- Glow-Wire Capable: No
- Net Weight: 6.000g
- Packaging: Bag
- Physical Dimensions: Dual row, 4.20mm pitch, 10 circuits
- Application: Power, Wire-to-Board, Wire-to-Wire
- Reference Drawing: 2070170000-PS-000
- RoHS Compliance: China RoHS, REACH SVHC Not Contained
- Use With: Mini-Fit Sigma Sealed Cap 2070190010, Mini-Fit TPA2 Male Crimp Terminal
- Mate with: Mini-Fit Jr. Receptacle Housing 5557, 46992, 172708
Buy the Buy Molex Mini-Fit Sigma Sealed Plug Housing Part Number 2070170010 Online
Order the Molex Mini-Fit Sigma Sealed Plug Housing online today and ensure your power systems are protected, reliable, and compliant with industry standards. Designed for durability with UL94V-0 nylon, it features a 4.20mm pitch with 10 circuits, suitable for wire-to-board and wire-to-wire connections. Operates from -40°C to +105°C, providing excellent thermal performance. Compatible with Mini-Fit Jr. receptacles, it offers a secure lock and effective sealing against moisture and contaminants. Perfect for industrial, automotive, and electronic applications needing a robust power connection solution.
Buy Molex 2070170010 now and experience unmatched reliability and performance for your power and electronic connections.
