MOLEX 2125201010 Mini-Fit Max Vertical Header
The MOLEX 212520-1010 Mini-Fit Max Vertical Header is a robust solution for wire-to-board power connections. Designed with a dual-row configuration and 10 circuits, this header provides a secure and reliable connection for various industrial applications. The tin plating ensures excellent conductivity and corrosion resistance, while the black liquid crystal polymer resin offers durability and insulation. Its vertical orientation and PCB locator features simplify integration into printed circuit boards, making it a versatile choice for power distribution in electronic devices and equipment. The header is also characterized by its breakaway design, keyed mating part, and polarized features, enhancing assembly and preventing misconnections.
MOLEX 2125201010 Mini-Fit Max Vertical Header Specifications:
- overview: Mini-Fit Family Power Connectors
- application: Power, Wire-to-Board
- circuits_loaded: 10
- circuits_maximum: 10
- color_resin: Black
- durability_mating_cycles: 30
- glow_wire_capable: Yes
- guide_to_mating_part: Yes
- lock_to_mating_part: Yes
- material_metal: Copper Alloy
- material_plating_mating: Tin (Sn)
- material_resin: Liquid Crystal Polymer
- number_of_rows: 2
- orientation: Vertical
- pcb_locator: Yes
- pcb_retention: Yes
- pcb_thickness_recommended: 1.60mm
- packaging_type: Tray
- pitch_mating_interface: 4.20mm
- pitch_termination_interface: 4.20mm
- polarized_to_mating_part: Yes
- polarized_to_pcb: Yes
- shrouded: Fully
- temperature_range_operating: -40° to +105°C
- termination_interface_style: Through Hole
- current_maximum_per_contact: 20.0A
- voltage_maximum: 600V AC (RMS)/DC
- material_info: Low-Halogen
- reach_svhc: Not Contained
