MOLEX 2132260610 PCB Receptacle
The CLIK-Mate Wire-to-Board PCB Receptacle features a 1.50mm pitch, single row, right-angle surface mount design with 6 circuits and natural color. It is gold-plated with 0.102 micrometers for durability and corrosion resistance, suitable for applications requiring a maximum of 2.0A current and 100V AC/DC voltage. Made from polyamide resin and copper alloy metal, it withstands operating temperatures from -40°C to +105°C. Compatible with CLIK-Mate housing and designed for reliable mating and retention in electronic assemblies.
MOLEX 2132260610 PCB Receptacle Specifications:
- Pitch - Mating Interface: 1.50mm
- Number of Circuits: 6
- Color - Resin: Natural
- Material - Metal: Copper Alloy
- Material - Plating Mating: Gold, 0.102 micrometers
- Material - Resin: Polyamide
- Durability (mating cycles max): 30
- Temperature Range - Operating: -40°C to +105°C
- Current - Maximum per Contact: 2.0A
- Voltage - Maximum: 100V AC/DC
- Termination Interface: Style: Surface Mount
- Orientation: Right Angle
- Surface Mount Compatible (SMC): Yes
Buy the Molex Series CLIK-Mate PCB Receptacle: 2132260610
Securely purchase the Molex Series CLIK-Mate PCB Receptacle 2132260610 online today to ensure reliable, high-performance connections for your electronic designs. Featuring a 1.50mm pitch and 6 circuits, this surface mount, gold-plated connector is ideal for demanding applications. Its durable polyamide housing and copper alloy contacts withstand extreme temperatures from -40°C to +105°C, providing long-lasting performance. With a maximum current of 2A and 100V, it offers excellent electrical ratings and compatibility with CLIK-Mate housings, making it suitable for various industrial and consumer electronics.
Order your Molex Series CLIK-Mate PCB Receptacle 2132260610 today and provide your projects with dependable, high-quality electrical connections.
