MOLEX 2153201062 Mini-Fit Jr. Power Connector
This Mini-Fit Jr. female-to-female cable assembly features a 300mm length, black color, and tin-plated contacts suitable for power applications. It connects two Mini-Fit Jr. connectors with 6 circuits in a single row, offering reliable Female-to-Female connectivity. Made from durable nylon resin and brass metal parts with tin plating, it supports up to 9.0A and 600V per contact. This assembly is ideal for wire-to-wire and connector-to-connector configurations in various electronic and power systems, ensuring secure, high-quality connections that meet RoHS compliance standards.
MOLEX 2153201062 Mini-Fit Jr. Power Connector Specifications:
- Cable Length: 300.00mm
- Number of Circuits: 6
- Color: Black
- Connector Gender: Female-Female
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Nylon
- Wire Insulation Diameter: 4.20mm
- Wire Size AWG: 16
- Current - Maximum per Contact: 9.0A
- Voltage - Maximum: 600V
- Lock to Mating Part: Yes
- Termination Interface Style: Crimp or Compression
- Net Weight: 47.36g
- Packaging Type: Bag
- Reference Drawing Number: 215321
- RoHS: Compliant
- Partial Width: 4.20mm
- Connector Series: Mini-Fit Jr.
- Application: Power, Wire-to-Wire, Connector to Connector
- Status: Active
Buy the Molex Series Mini-Fit Jr. Power Connector: 2153201062
Purchase the Molex Mini-Fit Jr. Power Connector cable assembly online today and experience dependable power connectivity in your electronic systems. Featuring a durable nylon body, tin-plated brass contacts, and a 300mm length with six circuits, this assembly is designed for power applications requiring up to 9A and 600V. Its female-to-female configuration makes it ideal for wire-to-wire connections, ensuring secure and stable links in power, industrial, and electronic projects. Shop now for quality and reliable performance.
Order your Molex Series Mini-Fit Jr. 2153201062 power connector cable today and ensure reliable high-current connections for your electronic projects.
Frequently Asked Questions
Where can I buy MOLEX 2153201062?
You can click on the BUY or RFQ button to purchase 2153201062 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2153201062?
You can download the 2153201062 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2153201062?
MOLEX
