MOLEX 2153222042 Mini-Fit Jr. Cable Assembly
The MOLEX 215322-2042 is a Mini-Fit Jr. male-to-male cable assembly designed for wire-to-wire power applications. It boasts a black nylon resin housing, gold plating on the mating interface, and tin plating on the termination interface. This assembly is RoHS compliant and features a single row configuration with a 4.20mm mating pitch. It is ideal for applications requiring a robust and reliable power connection.
Authorized Distributors
Source:Mouser Electronics
Part No:215322-2042
Stock:0
Inv Date:05-30-2026
Price: Unit price: $5.57
Buy/RFQ:
Source:RS Americas, Inc
Part No:215322-2042
Stock:0
Inv Date:05-29-2026
Price: Unit price: $5.68
Buy/RFQ:
MOLEX 2153222042 Mini-Fit Jr. Cable Assembly Specifications:
- overview: Mini-Fit Family Power Connectors
- application: Power, Wire-to-Wire Assembly
- configuration: Dual Ended
- connectors: Connector to Connector Mini-Fit Jr. Both Ends
- cable_length: 300.00mm
- circuits_loaded: 4
- color_resin: Black
- material_metal: Brass
- plating_mating: Gold (Au)
- plating_termination: Tin
- material_resin: Nylon
- net_weight_g: 32.390
- number_of_rows: 1
- packaging_type: Bag
- pitch_mating_interface: 4.20mm
- plating_min_mating: 0.762µm
- plating_min_termination: 2.032µm
- single_ended: No
- termination_interface_style: Crimp or Compression
- wire_insulation_diameter_mm: 1.80-3.10mm
- wire_size_awg: 16
- wire_cable_type: UL 1015
- current_maximum_per_contact_a: 9.0
- voltage_maximum_v: 600
- upc: 193264597468
- material_info: Not Low-Halogen
- reach_svhc: Not Contained
- mates_with: Mini-Fit Jr. Receptacle Housing 5557, Mini-Fit TPA2 Cable Assembly 145135
- sales_drawing: 2153222041-000
