MOLEX 2170630067 Micro-One Wire-to-Board Header
The MOLEX 217063-0067 is a Micro-One wire-to-board header, part of the 217063 series. This header is designed for vertical mounting and offers a 2.00mm pitch with 6 circuits. It features a tin-bismuth plating, providing excellent solderability and corrosion resistance. The header is glow-wire capable, meeting specific safety standards for electrical components. Its polyamide resin construction and black color contribute to its durability and aesthetic appeal. It is commonly used in applications requiring secure and reliable wire-to-board connections, such as consumer electronics, automotive systems, and industrial equipment.
MOLEX 2170630067 Micro-One Wire-to-Board Header Specifications:
- overview: Micro-One Wire-to-Board Connector System
- description: Micro-One Wire-to-Board Header, Vertical, 2.00mm Pitch, Single Row, Glow-Wire Capable, 6 Circuits, Tin-Bismuth Plating, Black, with Cover Tape
- series: 217063
- circuits_loaded: 6
- circuits_maximum: 6
- color_resin: Black
- durability_mating_cycles: 30
- glow_wire_capable: Yes
- lock_to_mating_part: Yes
- material_metal: Brass
- material_plating: Tin-Bismuth
- material_resin: Polyamide
- net_weight: 1094.241/mg
- number_of_rows: 1
- orientation: Vertical
- pcb_retention: Yes
- packaging_type: Embossed Tape on Reel
- pitch_mating_interface: 2.00mm
- polarized_to_pcb: Yes
- temperature_range_operating: -40° to +105°C
- termination_interface_style: Surface Mount
- current_maximum_per_contact: 4.0A
- voltage_maximum: 250V AC (RMS)/DC
- reach_svhc: Not Contained
- halogen_free_status: Not Low-Halogen
