MOLEX 2174661052 Power Cable Assembly
The Ultra-Fit Female-to-Pigtail Off-the-Shelf Cable Assembly with a 3.50mm pitch features a single row configuration and measures 300mm in length. Designed for power and signal transmission, it includes 5 circuits with a black nylon resin housing. The assembly uses high-conductivity copper with tin plating for reliable electrical contact and durability. Suitable for various electronic applications, this crimp or compression termination cable supports a maximum current of 14A and a maximum voltage of 600V AC/DC. It complies with RoHS and UL standards, ensuring safety and environmental friendliness.
MOLEX 2174661052 Power Cable Assembly Specifications:
- Pitch - Mating Interface: 3.50mm
- Cable Length: 300.00mm
- Circuits: 5
- Color - Resin: Black
- Gender: Female-Pigtail
- Material - Metal: High Conductivity Copper
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Nylon
- Wire Insulation Diameter: 2.03-2.39mm
- Wire Size AWG: 16
- Current - Maximum per Contact: 14.0A
- Voltage - Maximum: 600V AC/DC
- Net Weight: 24.068g
- Packaging Type: Bag
- Lock to Mating Part: Yes
- Assembly Configuration: Connector to Connector
- Reference - Drawing Numbers: 2174661051-000
- RoHS Compliant: Yes
- Halogen-Free: No
- ELV Status: Not Relevant
- EU RoHS: Compliant
- REACH SVHC: Not Contained
Buy the Molex Series Ultra-Fit Female-to-Pigtail: 2174661052
Order the Molex Ultra-Fit Female-to-Pigtail Cable Assembly with 3.50mm pitch and 5 circuits today. Designed for power and signal applications, it features a durable nylon housing, tin-plated high-conductivity copper contacts, and a 300mm length. Suitable for powering electronic components with a maximum current of 14A and voltage of 600V. RoHS compliant, with reliable crimp or compression terminations, this assembly ensures safety, durability, and top performance in your electronic projects. Shop online now for fast delivery.
Get Molex Ultra-Fit Female-to-Pigtail 2174661052 today—built for power transmission and reliable connections with high durability.
Frequently Asked Questions
Where can I buy MOLEX 2174661052?
You can click on the BUY or RFQ button to purchase 2174661052 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 2174661052?
You can download the 2174661052 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 2174661052?
MOLEX
