MOLEX 26481101 Board-to-Board Connector
The KK 396 Breakaway Header from Molex is a vertical, 10-circuit connector featuring tin (Sn) plating, designed for reliable board-to-board and wire-to-board connections. Made from durable polyester resin with brass metal components, it supports up to 11-20-0901 application tooling and withstands a temperature range of -55°C to +105°C. Ideal for industrial automation, electronics, and power applications, this high-quality header offers excellent durability with up to 20 mating cycles, ensuring stable electrical contact and secure connections in demanding environments.
MOLEX 26481101 Board-to-Board Connector Specifications:
- Number of Circuits: 10
- Orientation: Vertical
- Color - Resin: None specified
- Material - Metal: Brass
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- PCB Tail Length: 3.96mm
- Pitch - Mating Interface: 3.96mm
- Voltage - Max: 250V
- Current - Max: 7.0A
- Temperature Range - Operating: -55°C to +105°C
- Durability (mating cycles max): 20
- Packaging: Bag
- Process Temperature Max: 235°C
- Process Capability: Lead-free, RoHS Compliant
Buy the Molex 0026481101 – Reliable Power and Signal Connectors for Industrial Applications
Purchase the Molex KK 396 Breakaway Header online today for robust, reliable connections in power and signal applications. Crafted with durable materials, it features a 10-circuit vertical design, tin-plated contacts, and supports up to 20 mating cycles. Its operating temperature range from -55°C to +105°C ensures dependable performance in industrial environments. Ideal for automation, control systems, and electronic devices, this high-quality connector guarantees secure, stable electrical contact for demanding manufacturing and engineering needs. Order now for fast delivery and excellent value.
Buy Molex 0026481101 now and experience unmatched reliability and performance with high-quality board-to-board and wire-to-board connectivity.
Frequently Asked Questions
Where can I buy MOLEX 26481101?
You can click on the BUY or RFQ button to purchase 26481101 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 26481101?
You can download the 26481101 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 26481101?
MOLEX
