MOLEX 460152006 Power Connector
The Mini-Fit Plus Connector System is a high-reliability, power wire-to-board connector featuring a dual-row, vertical layout with 20 circuits. Made of durable nylon PA Polyamide Nylon 6/6 with UL 94V-2 flammability rating, it supports up to 13A per circuit and 600V maximum. The connector includes a tin-plated copper alloy metal contact, with PCB connections through a 1.80mm tail length and a 4.20mm pitch interface. Suitable for industrial power applications, it offers robust mating cycles, polarization, and RoHS compliance, ensuring safety and longevity in demanding environments.
MOLEX 460152006 Power Connector Specifications:
- Material: Nylon PA Polyamide Nylon 6/6
- Flammability: UL 94V-2
- Contact Material: Copper Alloy
- Contact Plating: Tin
- Wire Range: Compatible with 16 AWG wire
- Maximum Current: 13A per circuit
- Maximum Voltage: 600V
- Number of Circuits: 20
- Number of Rows: 2
- Orientation: Vertical
- Tail Length: 1.80mm
- Pitch: 4.20mm
- Operating Temperature Range: -40°C to +105°C
- Plating Minimum - Mating: 2.540um
- Plating Minimum - Termination: 1.270um
- Lock Type: None
- PCB Thickness - Recommended: Not specified
- Certification: UL, CSA, RoHS compliant
- Solder Process Capability: Wave solder, max process temp 260°C, duration 5 seconds
Buy the Molex 460152006 – Reliable Power Connector for Industrial Applications
Purchase the Molex Power Connector system online today to ensure robust electrical connections for power applications. This dual-row, 20-circuit connector offers excellent durability, maximum current of 13A per circuit, and a maximum voltage of 600V ideal for industrial machinery. Made of high-quality nylon with tin-plated copper contacts, it features a 4.20mm pitch, 1.80mm tail length, and vertical orientation for secure PCB mounting. RoHS compliant, UL listed, and CSA certified, it guarantees safety, long-term reliability, and easy installation — perfect for demanding power distribution needs.
Get Molex 460152006 today—built for power robustness, high current capacity, and long-lasting durability in industrial settings.
Frequently Asked Questions
Where can I buy MOLEX 460152006?
You can click on the BUY or RFQ button to purchase 460152006 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 460152006?
You can download the 460152006 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 460152006?
MOLEX
