MOLEX 5016453220 iGrid Wire-to-Board Header
The MOLEX 501645-3220 iGrid Wire-to-Board Header is a robust connector solution for wire-to-board applications. With a 2.00mm pitch and 32 circuits in a dual-row configuration, it provides reliable signal transmission. The vertical orientation and tin plating ensure efficient connectivity, while the PCB locator simplifies alignment and integration. Constructed with brass and nylon materials, this header offers durability and performance in demanding industrial environments. It is suitable for applications requiring secure and stable connections between wires and printed circuit boards.
MOLEX 5016453220 iGrid Wire-to-Board Header Specifications:
- pitch_mating_interface: 2.00mm
- circuits_loaded: 32
- circuits_maximum: 32
- material_plating_mating: Tin
- material_plating_termination: Tin
- pcb_tail_length: 3.20mm
- current_maximum_per_contact: 2.0A
- voltage_maximum: 250V AC (RMS)/DC
- operating_temperature_range: -40° to +105°C
- termination_interface_style: Through Hole
- material_resin: Nylon
- material_metal: Brass
- number_of_rows: 2
- orientation: Vertical
- pcb_retention: None
- pcb_thickness_recommended: 1.20mm, 1.60mm
- stackable: No
- surface_mount_compatible: No
- keying_to_mating_part: Yes
- lock_to_mating_part: Yes
- flammability: 94V-0
- glow_wire_capable: No
- polarized_to_mating_part: Yes
- polarized_to_pcb: Yes
- breakaway: No
- durability_mating_cycles_max: 30
