MOLEX 5022311500 FFC FPC Connector
The Easy-On FFC-FPC Connector features a 0.50mm pitch, vertical SMT design with ZIF actuation, ideal for LVDS applications. It supports 15 circuits and has a mated height of 6.05mm. Made of phosphor bronze with gold and tin plating, it offers durability for up to 20 mating cycles. Operating within a temperature range of -25°C to +85°C, it ensures reliable electrical performance with a maximum current of 0.4A per contact and voltage rating of 50V AC/DC. Suitable for surface mount PCB applications, it is packaged on embossed tape on reel for ease of assembly.
MOLEX 5022311500 FFC FPC Connector Specifications:
- Pitch: 0.50mm
- Circuits: 15
- Height: 6.05mm
- Actuator Type: Flip
- Material: Phosphor bronze
- Plating: Gold and Tin
- Durability: 20 mating cycles
- Operating Temperature: -25°C to +85°C
- Maximum Current: 0.4A per contact
- Voltage Rating: 50V AC/DC
- Mounting: Surface mount
- Packaging: Embossed tape on reel
- Color: Brown, Natural
- Orientation: Vertical
- Mating Interface Pitch: 0.50mm
- Termination Interface Pitch: 0.50mm
- RoHS, China RoHS, REACH compliant
Buy the Molex 5022311500 – Reliable FFC-FPC Connector for Industrial Applications
Enhance your electronic assemblies with the Molex FFC FPC Connector. Featuring a 0.50mm pitch, ZIF actuation, and 15 circuits, it guarantees secure data transmission for LVDS and other applications. Its vertical SMT surface mount design ensures easy installation and excellent durability, supporting up to 20 mating cycles. Operating confidently within -25°C to +85°C, it provides reliable electrical performance at 50V and 0.4A. Ideal for compact, high-density electronic devices, this connector is available for quick online purchase to streamline your production process.
Buy Molex 5022311500 now and experience unmatched reliability and performance for your electronic connector needs.
Frequently Asked Questions
Where can I buy MOLEX 5022311500?
You can click on the BUY or RFQ button to purchase 5022311500 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 5022311500?
You can download the 5022311500 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 5022311500?
MOLEX
