MOLEX 5037640301 Wire-to-Board Connector
The Pico-Lock Connector System is a reliable 1.00mm pitch wire-to-board connector designed for compact electronic applications. It features a single-row, positive lock receptacle crimp housing with three circuits, made from high-temperature thermoplastic, ensuring durability and stability across operating temperatures from -40°C to +105°C. The connector is black, stackable, and polarized to mating parts for secure connections. Suitable for various electronic assemblies, it facilitates easy crimping and mounting, offering RoHS compliance and halogen-free construction for environmentally friendly applications.
MOLEX 5037640301 Wire-to-Board Connector Specifications:
- Pitch - Mating Interface: 1.00mm
- Circuits (maximum): 3
- Color - Resin: Black
- Material - Resin: High Temperature Thermoplastic
- Temperature Range - Operating: -40°C to +105°C
- Net Weight: 23.000/mg
- Gender: Receptacle
- Number of Rows: 1
- Packaging Type: Bag
- Lock to Mating Part: Yes
- Polarized to Mating Part: Yes
- Stackable: No
- Glow-Wire Capable: No
- Keying to Mating Part: None
- Environmental Compliance: RoHS, China RoHS, Halogen-Free, Low-Halogen, REACH SVHC Not Contained
Buy the Molex 5037640301 – Reliable Wire-to-Board Connector for Industrial Applications
Buy the Molex Pico-Lock Wire-to-Board Connector Series5037645037640301 today to ensure secure, reliable electrical connections in your electronic projects. This 1.00mm pitch connector features a positive lock and three circuits, constructed from high-temperature thermoplastic for durability. Its stackable, polarized design simplifies assembly and maintenance, making it ideal for compact, high-performance electronics. RoHS compliant and halogen-free, this connector supports environmentally friendly manufacturing. Order online now for fast delivery and experience the trusted quality of Molex in your next electronic innovation.
Order your Molex Series503764 5037640301 today and give your projects the dependable quality they deserve with high-temperature thermoplastic construction.
Frequently Asked Questions
Where can I buy MOLEX 5037640301?
You can click on the BUY or RFQ button to purchase 5037640301 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 5037640301?
You can download the 5037640301 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 5037640301?
MOLEX
