MOLEX 512422000 Wire-to-Board Connector
The MicroClasp Wire-to-Board Receptacle Housing features a 2.00mm pitch, dual-row configuration, positive lock mechanism, and terminal retainer option. Ideal for compact electronic assemblies, it supports up to 20 circuits in natural color resin. Designed for reliable, secure connections, this housing withstands operating temperatures from -25°C to +85°C. It is RoHS compliant, halogen-free, and suitable for applications requiring durable wire-to-board connections. The product ensures easy mating and un-mating with a secure lock and is compatible with various Crimp Housings for versatile deployment.
MOLEX 512422000 Wire-to-Board Connector Specifications:
- Pitch - Mating Interface: 2.00mm
- Number of Circuits: 20
- Number of Rows: 2
- Material - Resin: Nylon
- Color: Natural
- Glow-Wire Capable: No
- Lock to Mating Part: Yes
- Operating Temperature Range: -25°C to +85°C
- Net Weight: Data not specified, standard packaging used
- Packaging Type: Bag
- Reference Drawing Numbers: 512429200-SPK-200, PS-51242-002-001
- RoHS Compliance: Yes
- Halogen-Free: No
- Application: Signal, Wire-to-Board
- Series: 51242
- Use With: 55767, 56134
- Mates With: 55763
Buy the Buy Molex MicroClasp Wire-to-Board Part Number 512422000 Online
Purchase the Molex MicroClasp Wire-to-Board Receptacle Housing online today. This 2.00mm pitch, dual-row connector supports up to 20 circuits and features a positive lock mechanism for secure connections. Made of high-quality nylon resin, it withstands operating temperatures from -25°C to +85°C. RoHS compliant and halogen-free, it is ideal for compact electronic devices needing reliable, easy-to-mate wire-to-board connections. Order now to ensure your assembly benefits from proven durability and precise fit, backed by Molex's trusted manufacturing standards.
Get Molex MicroClasp 512422000 today—designed for secure, reliable wire-to-board connections with a 2.00mm pitch and 20 circuits, built for durability.
Frequently Asked Questions
Where can I buy MOLEX 512422000?
You can click on the BUY or RFQ button to purchase 512422000 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 512422000?
You can download the 512422000 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 512422000?
MOLEX
