MOLEX 525592033 FFC Connector
The Molex easy-on FFC/FPC connector features a 0.50mm pitch and vertical slider design, supporting 20 circuits with tin-silver-bismuth plating for reliable connections. It is suitable for surface-mount technology, providing a height of 3.90mm and a durable mating cycle of 20 times. Constructed with phosphor bronze contacts and nylon housing, it operates within a temperature range of -40°C to +85°C. Compliant with RoHS, ELV, and REACH standards, this connector is ideal for compact, high-density electronics in industrial and consumer applications.
MOLEX 525592033 FFC Connector Specifications:
- Pitch: 0.50mm
- Number of Circuits: 20
- Height: 3.90mm
- Contact Material: Phosphor Bronze
- Plating - Mating: Tin-Silver-Bismuth
- Plating - Termination: Tin-Silver-Bismuth
- Housing Material: Nylon
- Operating Temperature Range: -40°C to +85°C
- Electrical Rating: 0.5A, 50V AC/DC
- Durability (Mating Cycles): 20
- Flammability Rating: 94V-0
- Mounting Type: Surface Mount
- Color: Natural
- Net Weight: 272.922 mg
- PCB Mounting: Yes
- Packaging: Embossed Tape on Reel
- RoHS, REACH, UL, China RoHS compliant
Buy the Molex 525592033 – Reliable FFC Connector for Industrial Applications
Purchase the Molex 525592033 FFC connector online today to ensure high-quality, durable, and reliable connections for your electronic projects. This connector features a 0.50mm pitch with 20 circuits, a vertical slider design, and RoHS compliance, making it ideal for high-density applications. Its surface-mount construction simplifies assembly, while the tin-silver-bismuth plating provides excellent conductivity and corrosion resistance. With a maximum operating temperature of -40°C to +85°C and a durability of 20 mating cycles, this connector guarantees long-lasting performance in demanding environments.
Get Molex 525592033 today—built for precise, reliable connections in compact electronic devices.
Frequently Asked Questions
Where can I buy MOLEX 525592033?
You can click on the BUY or RFQ button to purchase 525592033 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 525592033?
You can download the 525592033 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 525592033?
MOLEX
