MOLEX 526101272 FFC/FPC Connector
The Easy-On FFC/FPC Connector with a 1.00mm pitch features vertical mounting, 12 circuits, and gold plating. Designed for flexible flat cables, it offers reliable connection with a height of 5.75mm and durable sliding actuator. This surface-mount connector complies with RoHS and UL standards, has a maximum current of 1.0A per contact, and operates within -40°C to +85°C. Made from phosphor bronze with a gold finish, it ensures high reliability in compact electronic assemblies for applications like mobile devices, displays, and communication equipment.
MOLEX 526101272 FFC/FPC Connector Specifications:
- Pitch - Mating Interface: 1.00mm
- Number of Circuits: 12
- Height: 5.75mm
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: Nylon
- Temperature Range - Operating: -40°C to +85°C
- Current - Maximum per Contact: 1.0A
- Voltage - Maximum: 125V AC/DC
- Flammability: 94V-0
- Color - Resin: Natural
- Durability (mating cycles max): 30
- Mated Height: 5.75mm
- PCB Mounting: Surface Mount
- Packaging Type: Embossed Tape on Reel
Buy the Molex Series Easy-On FFC-FPC Connector: 526101272
Secure your electronic assemblies with the Molex Easy-On FFC/FPC Connector, featuring a 1.00mm pitch, 12 circuits, gold plating, and a durable sliding actuator. This surface-mount component is RoHS and UL compliant, operates from -40°C to +85°C, and provides reliable electrical contact with a maximum current of 1.0A per contact. Designed for flexible flat cables, it ensures a stable and secure connection in mobile devices, displays, and other compact electronics, simplifying assembly and reducing maintenance costs.
Buy Molex 526101272 now and experience unmatched reliability and high-performance connection solutions for compact electronic devices.
Frequently Asked Questions
Where can I buy MOLEX 526101272?
You can click on the BUY or RFQ button to purchase 526101272 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 526101272?
You can download the 526101272 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 526101272?
MOLEX
