MOLEX 559350210 MicroClasp Wire-to-Board Header
The MOLEX 55935-0210 MicroClasp™ Wire-to-Board Header is a compact and reliable solution for connecting wires to printed circuit boards. Designed with a 2.00mm pitch and a right-angle orientation, this header is ideal for applications where space is limited. It features 2 circuits and a PCB locator to simplify assembly and ensure accurate placement. The header is constructed with durable materials and offers excellent electrical performance, making it suitable for a wide range of industrial and consumer electronics applications. It is currently an active part and RoHS compliant.
MOLEX 559350210 MicroClasp Wire-to-Board Header Specifications:
- pitch_mating_interface: 2.00mm
- circuits_maximum: 2
- material_plating_mating: Tin
- material_resin: Polyester
- pcb_tail_length: 3.20mm
- current_max_per_contact: 3A
- voltage_max: 250V
- material_plating_termination: Tin
- number_of_rows: 1
- temperature_range_operating: -25°C to +85°C
- termination_interface_style: Through Hole
- pcb_thickness_recommended: 1.60mm
- durability_mating_cycles_max: 30
- net_weight: 379.200/mg
- orientation: Right Angle
- pcb_locator: Yes
- pcb_retention: Yes
- color_resin: Natural
- breakaway_circuits_loaded: No
- guide_to_mating_part: No
- keying_to_mating_part: No
- lock_to_mating_part: No
- shrouded: Fully
- stackable: No
- smc_compatible: No
- glow_wire_compliant: No
