MOLEX 705530008 Signal Header
The 2.54mm pitch SL Header is a low-profile, single-row, shrouded signal connector designed for PCB to wire applications. It features 9 circuits with gold and tin plating for reliable electrical connections, durable up to 50 mating cycles, and operates within a temperature range of -40°C to +105°C. Made from high-temperature thermoplastic with brass and phosphor bronze components, it ensures robust performance. Suitable for signal, wire-to-board connections, this right-angle connector has a 3.30mm PC tail length and is compliant with RoHS standards, making it ideal for industrial and electronic assembly use.
MOLEX 705530008 Signal Header Specifications:
- Pitch: 2.54mm
- Number of Circuits: 9
- Material - Metal: Brass, Phosphor Bronze
- Material - Plating: Gold (Mating), Tin (Terminations)
- Color: Black
- Durability: Up to 50 mating cycles
- Operating Temperature Range: -40°C to +105°C
- Voltage - Maximum: 250V
- Current - Maximum per Contact: 3.0A
- Termination Style: Through Hole
- Lock to Mating Part: Yes
- Guide to Mating Part: Yes
- Flammability: UL 94V-0
- Packaging: Tube
- PCB Thickness - Recommended: 1.60mm
- Guide: Yes, Fully Shrouded
- Stackable: No
Buy the Molex 705530008 – Reliable Signal Connectors for Industrial Applications
Order the Molex 705530008 signal header online today and enjoy reliable, high-quality connections for your industrial and electronics projects. This connector offers a 2.54mm pitch, 9 circuits, gold and tin plating, and a durable low-profile design. It supports up to 250V and 3.0A per contact, ensuring efficient power and signal transmission. Perfect for wire-to-board applications, its robust construction withstands up to 50 mating cycles, operating reliably across temperatures from -40°C to +105°C. Buy now for quick delivery and guaranteed quality.
Get Molex 705530008 today—built for precision and long-lasting durability in industrial and electronic assemblies.
Frequently Asked Questions
Where can I buy MOLEX 705530008?
You can click on the BUY or RFQ button to purchase 705530008 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 705530008?
You can download the 705530008 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 705530008?
MOLEX
