MOLEX 705530012 Signal Header
The SL modular connector series features a 2.54mm pitch SL header with a low profile design, single row configuration, and a 3.05mm pocket. It has a shrouded design with 13 circuits, gold selective plating on contacts, and tin plating on the PC tail. Suitable for signal applications and wire-to-board connections, it supports a maximum of 50 mating cycles, operates within -40°C to +105°C, and can carry up to 3A per contact. Its durable construction and reliable locking mechanism make it ideal for compact electronic assemblies.
MOLEX 705530012 Signal Header Specifications:
- Pitch - Mating Interface: 2.54mm
- Number of Circuits: 13
- Color - Resin: Black
- Flammability: 94V-0
- Material - Metal: Brass, Phosphor Bronze
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Temperature Range - Operating: -40°C to +105°C
- Current - Maximum per Contact: 3.0A
- Voltage - Maximum: 250V
- Orientation: Right Angle
- Lock to Mating Part: Yes
- Durability (mating cycles max): 50
- Net Weight: 2.880 g
- Packaging: Tube
- PC Tail Length: 3.30mm
- PCB Thickness - Recommended: 1.60mm
- Termination Interface Style: Through Hole
Buy the Molex 705530012 – Reliable Signal Connector for Industrial Applications
Order the Molex 705530012 signal header online today—perfect for wire-to-board connections in electronic assemblies. It features 13 circuits with a 2.54mm pitch, gold and tin plating for reliable conductivity, and a durable high-temperature thermoplastic body. Its right-angle orientation and shrouded design ensure secure connections, while the maximum current per contact is 3A. Designed for operating temperatures from -40°C to +105°C, it supports up to 50 mating cycles, making it ideal for demanding industrial and electronic applications.
Get Molex 705530012 today—built for precise signal connections and long-lasting durability in compact electronic devices.
Frequently Asked Questions
Where can I buy MOLEX 705530012?
You can click on the BUY or RFQ button to purchase 705530012 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 705530012?
You can download the 705530012 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 705530012?
MOLEX
