MOLEX 875681463 Milli-Grid Connector
The Milli-Grid Cable-to-Board Receptacle from the Series 87568 is a high-quality, dual-row connector designed for reliable PCB connections. It features 14 gold-plated circuits with a 2.00mm pitch, suitable for applications requiring durability up to 100 mating cycles. Made from copper alloy with polyester resin, it operates efficiently between -20°C to +85°C. RoHS and REACH compliant, this female connector ensures long-lasting performance in electronic assemblies with a maximum current of 1.0A per contact and voltage up to 125V. It’s ideal for precise, space-saving circuitry connections.
MOLEX 875681463 Milli-Grid Connector Specifications:
- Circuits (loaded): 14
- Color - Resin: Black
- Durability (mating cycles max): 100
- Flammability: 94V-0
- Material - Metal: Copper Alloy
- Material - Plating: Mating Gold
- Material - Resin: Polyester
- Net Weight: 0.883 g
- Number of Rows: 2
- Pitch - Mating Interface: 2.00mm
- Temperature Range - Operating: -20°C to +85°C
- Termination Interface: Style IDT or Pierce
- Wire Size AWG: 28
- Current - Maximum per Contact: 1.0A
- Voltage - Maximum: 125V
- RoHS and REACH compliant
- Mates With: 87831 Vertical PCB Header, 87832 Surface Mount PCB Header, 87833 Right Angle PCB Header
Buy the Molex Series 87568 Milli-Grid Cable-to-Board Receptacle: 875681463
Order the Molex Milli-Grid Connector from Series 87568 online today to ensure reliable and secure PCB connections. Designed with 14 gold-plated circuits and a 2.00mm pitch, this connector is perfect for applications requiring high durability and performance. Its construction from copper alloy and polyester resin guarantees stability and longevity even in demanding environments. RoHS and REACH compliant, it supports up to 1.0A per contact at 125V, making it ideal for compact, high-precision electronic assemblies. Purchase online for quick delivery and expert support.
Get Molex 875681463 today—built for precision and long-lasting durability in electronic circuit connections.
Frequently Asked Questions
Where can I buy MOLEX 875681463?
You can click on the BUY or RFQ button to purchase 875681463 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 875681463?
You can download the 875681463 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 875681463?
MOLEX
