MOLEX 878320406 Milli-Grid Header Connector
The MOLEX 87832-0406 Milli-Grid Header is a robust connector solution designed for surface mount applications in a variety of industries. Featuring 4 circuits and a gold plating finish, it ensures reliable electrical connectivity. The shrouded design provides protection against environmental factors and accidental contact. This connector is suitable for wire-to-board applications and is often used in automotive and industrial equipment where secure and dependable connections are essential. Its vertical orientation and surface mount compatibility make it easy to integrate into various PCB designs.
MOLEX 878320406 Milli-Grid Header Connector Specifications:
- Circuits: 4
- Plating Mating: 0.381µm Gold (Au)
- Plating Termination: 1.905µm Tin
- Flammability: 94V-0
- Operating Temperature Range: -55° to +105°C
- Maximum Current per Contact: 2.0A
- Maximum Voltage: 125V
- Material - Resin: Nylon
- Material - Metal: Phosphor Bronze
- PCB Locator: No
- Lock to Mating Part: Yes
- Keying to Mating Part: Yes
- Mates With: 79107, 78787, 79108, 79109, 78788, 51110, 87568
- Solder Process Temperature Max C: 260
- Lead-free Process Capability: REFLOW
Buy the 87832-0406 MOLEX Milli-Grid Header Connector | myMectronic
Purchase the MOLEX 87832-0406 Milli-Grid Header securely and reliably through our online platform.
Buy Now
Frequently Asked Questions
Where can I buy MOLEX 878320406?
You can click on the BUY or RFQ button to purchase 878320406 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 878320406?
You can download the 878320406 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 878320406?
MOLEX
