MOLEX 878325422 Milli-Grid Header
The MOLEX 0878325422 is a Milli-Grid Header designed for robust wire-to-board connectivity. This surface mount header features 10 circuits and utilizes 0.38µm gold plating on the mating interface and tin plating on the termination interface, ensuring excellent electrical performance and durability. The shrouded design provides protection against environmental factors and accidental shorts. It is ideal for applications requiring a secure and reliable connection, particularly in automotive and industrial settings. Its vertical orientation and compatibility with robotic placement further enhance its suitability for automated assembly processes.
MOLEX 878325422 Milli-Grid Header Specifications:
- overview: Milli-Grid Connector System
- description: Milli-Grid Header, Surface Mount, Vertical, Shrouded, Lead-Free, 10 Circuits, 0.38µm Gold (Au) Plating, with Pick-and-Place Cap
- series: 87832
- circuits_loaded: 10
- circuits_maximum: 10
- color_resin: Black
- durability_mating_cycles: 100
- first_mate_last_break: No
- flammability: 94V-0
- glow_wire_capable: No
- guide_to_mating_part: Yes
- lock_to_mating_part: Yes
- material_metal: Phosphor Bronze
- material_plating_mating: Gold
- material_plating_termination: Tin
- material_resin: Nylon
- net_weight_g: 0.476
- number_of_rows: 2
- orientation: Vertical
- pcb_locator: No
- pcb_retention: None
- packaging_type: Embossed Tape on Reel
- pitch_mating_interface: 2.00mm
- pitch_termination_interface: 2.00mm
- plating_min_mating: 0.381µm
- plating_min_termination: 1.905µm
- polarized_to_pcb: No
- robotic_placement: Yes
- shrouded: Fully
- surface_mount_compatible: Yes
- temperature_range_operating: -55° to +105°C
- termination_interface_style: Surface Mount
- current_maximum_per_contact: 2.0A
- voltage_maximum: 125V
- lead_free_process_capability: REFLOW
- max_cycles_at_max_process_temperature: 001
- process_temperature_max_c: 260
- reach_svhc: Not Contained
- halogen_free_status: Not Low-Halogen
- elv: Not Relevant
- rohs: Compliant
- phthalates: Not Contained
- packaging_specification: PK-87831-001-001, PK-87832-300-001
- product_specification: PS-87831-027-001
- sales_drawing: SD-87832-0001-001
