MOLEX 901220800 PCB Header
The Molex C-Grid I1I™ is a 2.54mm pitch PCB header with dual row configuration, designed for signal and wire-to-board applications. It features a 0.38um gold selective plating for reliable contact and corrosion resistance. The header supports up to 80 circuits, is right angle oriented, and constructed from durable thermoplastic polyester with brass metal components. It operates within a temperature range of -55°C to +125°C. Suitable for high-density, reliable electrical connections in industrial and electronic manufacturing, this header is a vital component for signal and power connections.
MOLEX 901220800 PCB Header Specifications:
- Pitch: 2.54mm
- Number of Circuits: 80
- Configuration: Dual row, right angle
- Material - Metal: Brass
- Material - Plating: Mating Gold, Termination Tin
- Material - Resin: Polyester, Black color
- Plating Min - Mating: 0.381µm, Min - Termination: 3.048µm
- PCB Tail Length: 2.90mm
- Temperature Range: -55°C to +125°C
- Voltage Rating: 350V
- Current - Max per Contact: 3A
- Packaging: Tray
- First Mate / Last Break: No
- Glow-Wire Compliant: No
- UL/CSA/IEC: RoHS, China RoHS, ELV compliant
- Wave Capable: Yes (TH only)
Buy the Molex 90122-0800 – Reliable PCB Header for Industrial Applications
Purchase the Molex PCB Header designed for signal and wire-to-board connections, featuring 80 circuits with a 2.54mm pitch, gold plating, and durable construction. This high-quality component operates over a wide temperature range of -55°C to +125°C, ensuring reliable performance in demanding industrial and electronic applications. Its right-angle orientation and compact size make it ideal for high-density assemblies. Order now online for quick delivery and ensure your manufacturing process benefits from our trusted, corrosion-resistant PCB headers, perfect for professional electronics and industrial equipment.
Get Molex 90122-0800 today—built for precision and high-density signal connections in industrial environments.
Frequently Asked Questions
Where can I buy MOLEX 901220800?
You can click on the BUY or RFQ button to purchase 901220800 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901220800?
You can download the 901220800 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901220800?
MOLEX
