MOLEX 901301120 PCB Header
The C-Grid III Header is a vertical, shrouded, dual-row interconnect with 20 circuits, designed for signal and wire-to-board applications. Made of durable polyester resin with brass metal contacts, it features tin plating over nickel for reliable connectivity. Rated for 350V AC/DC and supporting up to 3.0A per contact, it withstands temperatures from -55°C to +125°C. The header is polarizable, stackable, and offers easy through-hole termination with a pitch of 2.54mm, ensuring secure and stable connections in complex electronic assemblies.
MOLEX 901301120 PCB Header Specifications:
- Circuits: 20, maximum 20
- Color: Black
- Material - Metal: Brass
- Material - Plating: Tin over Nickel
- Material - Resin: Polyester
- Flammability: 94V-0
- Durability: 30 mating cycles
- Guide to Mating Part No: Yes
- Lock to Mating Part: Yes
- Orientation: Vertical
- PCB Thickness - Recommended: 1.60mm
- Pitch - Mating Interface: 2.54mm
- Temperature Range - Operating: -55°C to +125°C
- Voltage: Max 350V AC/DC
- Current per contact: 3.0A
- Termination Style: Through Hole
- Packaging: Tray
- RoHS Compliance: Yes
- UL Certification: E29179
- CSA Certification: LR19980
Buy the Buy Molex C-Grid III Part Number 901301120 Online
Purchase the Molex C-Grid III PCB Header online today to ensure your electronic projects benefit from a high-quality, durable, and reliable interconnect solution. Designed with 20 circuits in a vertical, shrouded form, it provides excellent stability and easy assembly. Constructed with premium brass contacts plated in tin over nickel, it supports up to 3A and 350V, with a temperature range of -55°C to +125°C. Perfect for signal wiring and wire-to-board connections, this header ensures secure, corrosion-resistant performance in demanding environments.
Order your Molex series 901301120 C-Grid III vertical shrouded PCB header today and enhance your electronic connections with reliable, durable, and high-temperature rated components.
Frequently Asked Questions
Where can I buy MOLEX 901301120?
You can click on the BUY or RFQ button to purchase 901301120 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901301120?
You can download the 901301120 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901301120?
MOLEX
