MOLEX 901361112 Wire-to-Board Header
The C-Grid III™ Header is a vertical, shrouded, single-row connector with 12 circuits, featuring a tin/lead (Sn) plating over nickel. Designed for wire-to-board applications, it operates within a temperature range of -55°C to +125°C. This UL-certified component has a 2.54mm pitch, a maximum current of 3A per contact, and a maximum voltage rating of 350V AC/DC. Its dimensions include a PCB tail length of 2.90mm and a net weight of approximately 1.75g, offering reliable electrical performance and easy mounting in various electronic assemblies.
MOLEX 901361112 Wire-to-Board Header Specifications:
- Number of Circuits: 12
- Orientation: Vertical
- Color - Resin: Polyester
- Flammability: UL Recognized
- Temperature Range - Operating: -55°C to +125°C
- Material - Metal: Not specified
- Material - Plating Mating: 3.048um Tin/Lead over Nickel
- Material - Plating Termination: 3.048um Tin/Lead
- Pitch - Mating Interface: 2.54mm
- Voltage - Maximum: 350V AC/DC
- Current - Maximum per Contact: 3A
- PCB Tail Length: 2.90mm
- Net Weight: 1.75g
- Packaging: Tray
- PC Board Thickness - Recommended: 1.60mm
- Shrouded: Yes
- Stackable: No
- RoHS Compliant: Yes
- Halogen-Free: No
- EU RoHS China RoHS: Compliant
- UL Certification: Yes
Buy the Molex Series C-Grid III 12 Circuits: 0901361112
Purchase the Molex C-Grid III™ Header with 12 circuits online today for robust wire-to-board connections. Featuring UL certification, tin/lead plating, and a 2.54mm pitch, this high-performance connector operates within a wide temperature range of -55°C to +125°C. Its compact design with a PCB tail length of 2.90mm ensures easy installation in electronic assemblies. With a maximum current of 3A per contact and a voltage rating of 350V AC/DC, it provides reliable electrical performance for demanding applications.
Buy Molex 0901361112 now and experience unmatched reliability and performance with high-quality wire-to-board connection solutions.
