MOLEX 901361205 Signal PCB Header
The C-Grid III Interconnects are high-reliability vertical headers designed for signal applications, featuring 5 circuits with a 2.54mm pitch and gold-plated contacts. These shrouded, single-row connectors are UL and CSA certified, operating within a temperature range of -55°C to +125°C. Made from durable brass with tin plating, they support a maximum current of 3.0A per contact and a maximum voltage of 350V AC/DC. Suitable for PCB mounting with a 2.90mm tail length, they are ideal for compact electronic assemblies and industrial equipment requiring secure, polarized connections.
MOLEX 901361205 Signal PCB Header Specifications:
- Number of Circuits: 5
- Circuits (Maximum): 5
- Color - Resin: Black
- Flammability: 94V-0
- Operating Temperature Range: -55°C to +125°C
- Material - Metal: Brass
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Net Weight: 0.880g
- Orientation: Vertical
- PC Tail Length: 2.90mm
- Pitch - Mating Interface: 2.54mm
- Termination Interface: Style: Through Hole
- Maximum Current per Contact: 3.0A
- Maximum Voltage: 350V AC/DC
- Certifications: UL, CSA
- Flammability: 94V-0
- RoHS Compliant: Yes
- Halogen-Free Status: Not Low-Halogen
- Solder Process: Lead-free, Wave Process Capability
Buy the Buy Molex C-Grid III Interconnects Part Number 0901361205 Online
Purchase Molex C-Grid III Signal PCB Header Part Number 0901361205 online to ensure your electronic projects and industrial equipment have dependable, high-quality interconnects. Designed with five circuits, gold-plated contacts, and UL/CSA certification, these vertical headers support up to 3A per contact and operate over -55°C to +125°C temperature range. Featuring a 2.54mm pitch, through-hole termination, and a durable brass construction, they provide secure, polarized connections essential for compact and reliable wiring solutions in modern electronic applications.
Get Molex C-Grid III Interconnects Part Number 0901361205 today—built for secure connections, high durability, and reliable electrical performance.
