MOLEX 901362105 PCB Header
The C-Grid Ill Header is a right-angle, shrouded PCB connector with a single row of 5 circuits, designed for signal wiring and board interconnections. Made from durable polyester resin with brass metal parts, it features gold-plated mating surfaces and tin-plated terminations for reliable connectivity. Operating in temperatures from -55°C to +125°C, this connector supports up to 3.0A per contact and 350V AC/DC, with a pitch of 2.54mm. It is RoHS and UL compliant, suitable for various electronic assembly applications.
MOLEX 901362105 PCB Header Specifications:
- Number of Circuits: 5
- Orientation: Right Angle
- Material - Metal: Brass
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Color - Resin: Black
- Flammability: 94V-0
- Temperature Range: -55°C to +125°C
- Maximum Current per Contact: 3.0A
- Maximum Voltage: 350V AC/DC
- Pitch - Mating Interface: 2.54mm
- PCB Thickness - Recommended: 1.60mm
- PC Tail Length: 2.90mm
- Packaging Type: Tray
- Lock to Mating Part: Yes
- Shrouded: Fully
- RoHS and UL compliant
- Solder Process: Lead-free, Wave solder capable
Buy the Molex Series 90136 C-Grid Ill Connector: 901362105
Purchase the Molex 901362105 PCB header online today and benefit from a high-quality, RoHS-compliant connector designed for reliable signal wiring. Featuring a right-angle, shrouded design with 5 circuits, this connector ensures secure, corrosion-resistant connections with gold-plated contacts. Its operating temperature range from -55°C to +125°C makes it suitable for demanding environments. Easy to install using lead-free wave soldering, this tray-packed component guarantees performance and durability for all your electronic assembly needs.
Buy Molex 901362105 now and experience unmatched reliability and performance in signal and data board connections with durable construction and secure locking features.
Frequently Asked Questions
Where can I buy MOLEX 901362105?
You can click on the BUY or RFQ button to purchase 901362105 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901362105?
You can download the 901362105 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901362105?
MOLEX
