MOLEX 901362205 Signal Connector
The C-Grid Ill Header is a reliable signal wire-to-board connector designed for industrial and electronic applications. Featuring a single row, right-angle, shrouded design with five circuits, it offers high durability. Made with brass contact material, gold-plated contacts for enhanced conductivity, and polyester resin insulation, it supports a temperature range from -55°C to +125°C. With a 2.54mm pitch, 0.38μm gold plating, and UL and CSA certifications, it ensures robust performance and easy assembly in complex systems.
MOLEX 901362205 Signal Connector Specifications:
- Material - Metal: Brass
- Material - Plating Mating: Gold
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Color: Black
- Flammability: 94V-0
- Circuits (Loaded): 5
- Circuits (Maximum): 5
- Orientation: Right Angle
- Guide to Mating Part No: None
- Lock to Mating Part: Yes
- PC Tail Length: 2.90mm
- PCB Thickness - Recommended: 1.60mm
- Pitch - Mating Interface: 2.54mm
- Maximum Voltage: 350V AC/DC
- Current per Contact: 3.0A
- Operating Temperature Range: -55°C to +125°C
- Termination Interface Style: Through Hole
- RoHS Compliant, UL and CSA Certified
Buy the Molex 90136 U–2013 Reliable Signal Connectors for Industrial Applications
Enhance your electronic assemblies with the Molex C-Grid Ill Signal Connector, featuring robust construction, gold-plated contacts for excellent conductivity, and a compact 2.54mm pitch. Designed for reliable wire-to-board connections, it supports a temperature range from -55°C to +125°C and meets UL and CSA standards. Ideal for industrial automation, control systems, and electronic equipment, this connector guarantees secure and durable electrical performance. Buy online now to streamline your assembly process and ensure consistent, high-quality connections for demanding applications.
Order your Molex Series 90136 C-Grid Ill connector today and ensure dependable signal connections for your industrial and electronic projects.
