MOLEX 901512108 Board-to-Board Connector
The C-Grid III PC Board Connector is a reliable dual-row, vertical, 8-circuit connector with tin (Sn) plating, designed for board-to-board signal applications. It features a high durability of up to 30 mating cycles, UL certification, and complies with RoHS standards. Made from phosphor bronze with polyester insulation, it supports a voltage of up to 350V and a maximum current of 3A per contact. Its compact design with 2.54mm pitch makes it ideal for space-sensitive electronic assemblies in industrial and electronic equipment. Suitable for PCB mounting with through-hole termination, it offers excellent connection stability and longevity.
MOLEX 901512108 Board-to-Board Connector Specifications:
- Circuits: 8
- Maximum Circuits: 8
- Color: Black
- Durability: 30 mating cycles
- Flammability: 94HB
- Material - Metal: Phosphor Bronze
- Material - Plating Mating: Tin
- Material - Plating Termination: Tin
- Material - Resin: Polyester
- Net Weight: 0.687 grams
- Number of Rows: 2
- Orientation: Vertical
- PC Tail Length: 2.90mm
- PCB Locator: No
- PCB Retention: None
- PCB Thickness - Recommended: 0.80mm, 1.70mm
- Packaging Type: Tube
- Pitch - Mating Interface: 2.54mm
- Pitch - Termination Interface: 2.54mm
- Plating min - Mating: Tin
- Plating min - Termination: Tin
- Polarized to PCB: No
- Stackable: Yes
- Surface Mount Compatible (SMC): No
- Temperature Range - Operating: -55°C to +125°C
- Termination Interface: Style: Through Hole
- Current - Maximum per Contact: 3A
- Grounding to PCB: No
- Voltage - Maximum: 350V
Buy the Molex 901512108 – Reliable Board-to-Board Connector for Industrial Applications
Discover the robust and reliable board-to-board connector designed for industrial electronics. With UL certification, RoHS compliance, and a durable design supporting up to 30 mating cycles, this 8-circuit connector ensures stable connections. Featuring tin plating for corrosion resistance, it supports a voltage of up to 350V, and a maximum current of 3A per contact. Its compact 2.54mm pitch and vertical orientation make it ideal for space-constrained electronic assemblies, providing long-lasting performance and easy installation for various industrial and electronic projects.
Get Molex 901512108 today—built for precision, high durability, and space-efficient PCB connections in industrial electronics.
Frequently Asked Questions
Where can I buy MOLEX 901512108?
You can click on the BUY or RFQ button to purchase 901512108 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 901512108?
You can download the 901512108 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 901512108?
MOLEX
