MOLEX 908140204 PCB Header
The Picoflex PF-50 Header is a surface-mount, vertical connector with four circuits, designed for PCB applications. Made from high-temperature thermoplastic and tin-plated for durability, it features a standard profile and reliable mating with a maximum of 4 cycles. Suitable for wire-to-board connections, it supports operating temperatures from -40°C to +105°C and carries a maximum current of 1.2A per contact and voltage of 250V. Its compact design and tape and reel packaging optimize convenience for automation and manufacturing processes.
MOLEX 908140204 PCB Header Specifications:
- Number of Circuits: 4
- Material - Resin: High-temperature thermoplastic
- Material - Plating Mating: Tin (Sn)
- Color: Natural
- Contact Material: Not specified, but tin-plated
- Voltage Rating: 250V
- Current per Contact: 1.2A
- Temperature Range: -40°C to +105°C
- Pitch - Mating Interface: 1.27mm
- Package Type: Tape and Reel
- Orientation: Vertical
- Mating Cycles Max: 4
- Surface Mount Compatible: Yes
- Flammability: Not specified
- Glow-Wire Capable: No
Buy the Molex Series Picoflex PCB Header: 908140204
Upgrade your electronic assembly with the Molex Series PCB Header designed for reliable PCB connections. This 4-circuit, surface-mount connector features high-temperature thermoplastic and tin plating for durability and corrosion resistance. It supports operating temperatures from -40°C to +105°C, handling up to 1.2A current per contact and 250V voltage. Its vertical orientation, compact design, and tape and reel packaging make it ideal for automated manufacturing, providing secure connections and ease of assembly for professional applications.
Order your Molex Series Picoflex PCB Header today and ensure reliable connections with high-quality, surface-mount design for your electronic projects.
Frequently Asked Questions
Where can I buy MOLEX 908140204?
You can click on the BUY or RFQ button to purchase 908140204 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 908140204?
You can download the 908140204 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 908140204?
MOLEX
