MOLEX 955012882 Modular Network Jack
This modular jack features a right-angle, through-hole design optimized for power over Ethernet applications. It has a low profile, 8/8 port configuration, and is keyed for secure connections. Made from high-temperature thermoplastic with gold over palladium nickel plating on copper alloy contacts, it offers durability with up to 2500 mating cycles. Certified to UL standards, it supports operating temperatures from -40°C to +85°C and has a maximum voltage of 125V DC and current of 1.5A per contact. Ideal for network installations requiring reliable and robust modular jacks.
MOLEX 955012882 Modular Network Jack Specifications:
- Material - Metal: Copper Alloy
- Material - Plating Mating: Gold over Palladium Nickel
- Material - Plating Termination: Tin
- Material - Resin: High Temperature Thermoplastic
- Dimensions: Jack Height 11.50mm, Port Configuration 1x1, Port Size 8/8
- Minimum Plating - Mating 0.051m, 0.600um
- Maximum Operating Temperature -40°C to +85°C
- Current - Max per Contact 1.5A
- Voltage - Max 125V DC
- Mating Cycles Max. 2500
- Flammability: UL 94V-0
- Certification: UL, RoHS Compliant
- Waterproof / Dustproof: No
- Orientation: Right Angle (Side Entry)
- Reflow Capable: Yes
- PCB Thickness - Recommended 1.57mm
- Packaging: Tray
- Ports: 1
- Positions / Loaded Contacts: 8/8
Buy the Buy Molex Modular Jack Part Number 955012882 Online
Order the Molex Modular Network Jack today for dependable network installations. Designed for high durability with up to 2500 mating cycles, this right-angle, through-hole jack is ideal for PoE applications. Made from high temperature thermoplastic and plated with gold over palladium nickel for excellent conductivity and corrosion resistance. Its compact low profile design supports PCB mounting with a 1.57mm recommended thickness. Certified by UL and RoHS compliant, it ensures safety, reliability, and long-lasting performance for your network infrastructure.
Get Molex 955012882 today—built for reliable network connectivity with high mating cycle durability and UL safety certification.
