MOLEX 955222647 Modular Jack
This high-performance modular jack is designed for power over Ethernet (PoE) applications, featuring a vertical, top-entry through-hole design with a high-profile structure and ribs for stability. Made from high-temperature thermoplastic with gold-over-palladium nickel plating, it supports 6/4 port configuration, and is compatible with 90075 modular plug. The jack withstands up to 125V DC and 1.5A current, with a maximum of 2500 mating cycles, ensuring durability and reliable connections in industrial networking and automation systems, suitable for security, telecom, and data transmission setups.
MOLEX 955222647 Modular Jack Specifications:
- Product Family: Magnetic
- Series: 95522
- Component Type: Modular Jacks/Plugs
- Performance Category: Power over Ethernet (PoE)
- Port Configuration: 6/4
- Port Count: 1
- Color - Resin: Black
- Flammability: 94V-0
- Durability (mating cycles max): 2500
- Jack Height: 16.25 mm
- Material - Metal: Copper Alloy
- Plating - Mating: Gold over Palladium Nickel
- Plating - Termination: Tin
- Temperature Range - Operating: -40°C to +85°C
- Voltage - Maximum: 125V DC
- Current - Maximum per Contact: 1.5A
- Waterproof / Dustproof: No
- Termination Interface: Through Hole
- Solder Process Data: Max. temperature 260°C for wave soldering, 5 seconds duration
- Dimensions and physical attributes: Tray mount, 1.57mm pitch, 1.02mm PCB thickness, 1.905um plating thickness, net weight approximately 2.85 grams.
Buy the Molex 95522 – Reliable Modular Jacks for Industrial Applications
Purchase the Molex 95522 modular jack online today and enhance your industrial networking setup. Designed for PoE applications, it features a durable, high-profile vertical through-hole design with top entry for ease of installation. Constructed from high-temperature thermoplastic with gold-over-palladium nickel plating, ensuring excellent corrosion resistance and longevity. Capable of handling up to 125V DC and 1.5A current, with an impressive 2500 mating cycles, it offers reliable performance for security, automation, and communication systems. Simplify your installation process with this high-quality, reflow-capable modular jack available online now.
Buy Molex 95522 modular jack now and experience unmatched durability and reliable network connectivity in industrial applications.
Frequently Asked Questions
Where can I buy MOLEX 955222647?
You can click on the BUY or RFQ button to purchase 955222647 from an authorized MOLEX distributor.
How do I troubleshoot issues or seek technical support for part 955222647?
You can download the 955222647 datasheet or visit the MOLEX website for support.
Who is the manufacturer of 955222647?
MOLEX
