MULTICOMP PRO 2211SM07GB1TB Pin Header
This 2.54mm pin header is a vertical, surface-mount device with a 1-row, staggered configuration, suitable for PCB connections in electronic assemblies. Made from high-temp nylon with UL94V-0 rating, it features gold-plated copper alloy contacts, offering excellent corrosion resistance and reliable electrical conductivity. The header supports current up to 3A and voltage up to 250V, with insulation resistance of 1000MO minimum, and withstands voltages of 600V AC for one minute. Operating temperature ranges from -40°C to +105°C, making it ideal for demanding industrial and consumer electronics applications.
MULTICOMP PRO 2211SM07GB1TB Pin Header Specifications:
- Current Rating: 3A
- Voltage Rating: 250V AC/DC
- Contact Resistance: 20mΩ Max.
- Insulation Resistance: 1000MO Min.
- Withstanding Voltage: 600V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- Materials and Finish: Copper Alloy with Gold Plating
- Insulator: High Temp. Plastic (Nylon 6T UL94V-0)
- Insulator Colour: Ivory
- Dimensions: Not specified
- Number of Positions: 7 (from part number 2211SM-07G-B1-TB)
Buy the Buy Multicomp Pro 2.54mm Pin Header Part Number 2211SM07GB1TB Online
Purchase the Multicomp Pro 2.54mm Pin Header 2211SM07GB1TB online today for dependable PCB interconnections in electronic projects. This vertical, SMD type features gold-plated copper alloy contacts for excellent conductivity and corrosion resistance. Made with high-temp nylon, it supports up to 3A current and 250V voltage, with an insulation resistance of 1000MO and withstands voltages of 600V AC for one minute, operating efficiently from -40°C to +105°C. Ideal for industrial and consumer electronics requiring robust performance and durable connection points.
Get Multicomp Pro 2.54mm Pin Header 2211SM07GB1TB today—designed for reliable PCB connections with high-temperature resistance and gold-plated contacts.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 2211SM07GB1TB?
You can click on the BUY or RFQ button to purchase 2211SM07GB1TB from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 2211SM07GB1TB?
You can download the 2211SM07GB1TB datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 2211SM07GB1TB?
MULTICOMP PRO
