MULTICOMP PRO 2212BR09G PCB Socket
This 2.54mm PCB socket features a single row, horizontal entry, through-hole design suitable for automation and prototyping on PCB assemblies. It supports a current rating of 3A AC/DC and a voltage rating of 250V AC/DC, making it versatile for various electronic applications. The component is constructed with an insulator made of nylon 6T (UL94V-0), copper alloy contacts with gold plating for reliable connectivity, and a compact size compatible with 2.54mm pitch headers. It withstands voltage of up to 1000V AC for one minute, operating from -40°C to +105°C, ensuring durability in rigorous environments. Its precise dimensions and high insulation resistance ensure stable performance. This socket fits 5 to 24 positions, suitable for PCB designs requiring secure and easy connection points, ideal for automation, control panels, and electronics development.
MULTICOMP PRO 2212BR09G PCB Socket Specifications:
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: 20mΩ Max.
- Insulation Resistance: 1000MΩ Min.
- Withstanding Voltage: 1000V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- Insulator Material: Nylon 6T (UL94V-0)
- Contact Material: Copper Alloy
- Finish: Gold Plated
- Dimensions: Suitable for 2.54mm pitch, 5 to 24 positions, compact design
- PCB Layout Tolerance: +0.05 mm
Buy the Buy Multicomp PCB Socket Part Number 2212BR09G Online
Enhance your electronic projects with the reliable Multicomp PCB Socket 2212BR09G, featuring a 2.54mm pitch, quick terminal connection, and gold-plated contacts for longevity. Perfect for automation, control panels, and prototyping, this socket ensures secure, durable connections for 5 to 24 position configurations. Its compact through-hole design operates efficiently from -40°C to +105°C, supporting 3A current and 250V voltage. Purchase the precise and dependable socket online today to streamline your PCB assembly process and ensure long-lasting performance in demanding environments.
Get Multicomp PCB Socket 2212BR09G today—designed for reliable and durable PCB connections in electronic systems.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 2212BR09G?
You can click on the BUY or RFQ button to purchase 2212BR09G from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 2212BR09G?
You can download the 2212BR09G datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 2212BR09G?
MULTICOMP PRO
