MULTICOMP PRO 2212BR14G PCB Socket
This 2.54mm pitch PCB socket is a single-row, through-hole type designed for reliable electrical connections in industrial electronics. It features a horizontal entry design, with current capacity of 3A, and a voltage rating of 250V AC/DC. Made from UL94V-0 nylon and copper alloy contact material, it’s gold plated for enhanced conductivity and corrosion resistance. The socket withstands 1000V AC for one minute, with an operating temperature range of -40°C to +105°C, suitable for various industrial, automation, and electronic manufacturing applications.
MULTICOMP PRO 2212BR14G PCB Socket Specifications:
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: 20mΩ Max
- Insulation Resistance: 1000MΩ Min
- Withstanding Voltage: 1000V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- Insulator Material: Nylon 6T (UL94V-0)
- Contact Material: Copper Alloy
- Finish: Gold Plated
- Dimensions: 2.54mm pitch, standard height 0.15 inches, hole diameter 0.030 inches, PCB layout tolerance +0.05 mm
- Number of Positions: Varies by model (5, 7, 9, 12, 14, 22, 24)
- Design: Horizontal entry, through-hole
Buy the Multicomp 2212BR14G – Reliable PCB Socket for Industrial Applications
Enhance your electronic projects with this high-quality 2.54mm pitch PCB socket. Designed for durability and reliable connections, it features gold-plated contacts, a current rating of 3A, and voltage support of 250V. Its through-hole, single-row design suits industrial and automation applications, ensuring secure and stable PCB mounting. Made from UL94V-0 insulator material and copper alloy contacts, it withstands up to 1000V AC for one minute and operates over a temperature range of -40°C to +105°C. Easy to install and highly dependable, order online now for fast delivery and seamless integration into your designs.
Buy Multicomp 2212BR14G now and experience unmatched reliability and performance for industrial PCB interconnections.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 2212BR14G?
You can click on the BUY or RFQ button to purchase 2212BR14G from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 2212BR14G?
You can download the 2212BR14G datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 2212BR14G?
MULTICOMP PRO
