MULTICOMP PRO 2213R60G 2.54mm Pin Header Right Angle
The MULTICOMP PRO 2213R-60G is a robust and reliable 2.54mm pitch pin header designed for through-hole mounting. Its right-angle configuration makes it ideal for applications where space is limited or a perpendicular connection is required. Constructed with copper alloy contacts and gold plating for excellent conductivity and corrosion resistance, and a PBT (UL94V-0) insulator for enhanced safety and durability. This header is suitable for a wide range of applications including industrial control panels, instrumentation, and consumer electronics.
MULTICOMP PRO 2213R60G 2.54mm Pin Header Right Angle Specifications:
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Contact Resistance: 20mΩ Max.
- Insulation Resistance: 1000MΩ Min.
- Withstanding Voltage: 600V AC for one minute
- Operating Temperature Range: -40°C to +105°C
- Insulator Material: PBT (UL94V-0)
- Insulator Colour: Black
- Contact Material: Copper Alloy
- Plating: Gold Plated
- Positions: 60
- Rows: 2
- Termination Type: Through Hole
