MULTICOMP PRO 2214S20SG85 PCB Socket
The 2214S-20SG-85 is a 20-way, 2-row PCB socket designed for industrial applications. It features a 2.54mm pitch, high-temperature black plastic insulation, and copper alloy contacts with a selective gold plating for reliable connectivity. This vertical, board-to-board socket supports solder termination and operates efficiently from -40°C to +105°C. It is rated at 3A and 250V, with a contact resistance of 20 milliohms and insulation resistance of 1000 megaohms. Ideal for precise electronic assemblies demanding durability and high performance.
MULTICOMP PRO 2214S20SG85 PCB Socket Specifications:
- Series: 2214S
- Connector Type: Receptacle
- Pitch Spacing: 2.54mm
- No. of Rows: 2
- No. of Contacts: 20
- Gender: Receptacle
- Contact Termination: Solder
- Contact Resistance: 20mΩ
- Current Rating: 3A
- Insulation Resistance: 1000MO
- Operating Temperature: -40°C to +105°C
- Voltage Rating: 250V AC, 600V
- Material: High Temperature Plastic, Copper Alloy
- Standard Colour: Black
- Contact Finish: Selective Gold Plated
Buy the Multicomp Series PCB Socket: 20-Way 2.54mm Pitch 2214S-20SG-85
Enhance your electronics assembly with this high-quality 20-way PCB socket featuring a 2.54mm pitch, gold-plated contacts, and durable high-temperature plastic insulation. Designed for reliable board-to-board connection, it supports solder termination and can operate efficiently from -40°C to +105°C. Rated at 3A and 250V, this versatile component ensures stable electrical performance in demanding environments. Easy to install and highly durable, it’s perfect for industrial electronics and automation projects. Order now to experience dependable connectivity and exceptional performance.
Get Multicomp Series PCB Socket 2214S-20SG-85 today—built for precision and long-lasting durability.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 2214S20SG85?
You can click on the BUY or RFQ button to purchase 2214S20SG85 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 2214S20SG85?
You can download the 2214S20SG85 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 2214S20SG85?
MULTICOMP PRO
