MULTICOMP PRO 2226B12 12 Way Wire to Board Housing
The MULTICOMP PRO 2226B-12 is a wire-to-board connector housing designed for secure and reliable connections. This 12-way housing utilizes a mini latch mechanism for positive locking and is ideal for applications in industrial control systems, automation equipment, and consumer electronics. Constructed with a polyester insulator and phosphor bronze contacts, it offers excellent electrical performance and durability. The tin or gold-plated contacts ensure low contact resistance and corrosion resistance, while the robust design supports a wide temperature range and withstands significant voltage and current levels.
MULTICOMP PRO 2226B12 12 Way Wire to Board Housing Specifications:
- Connector Type: Wire to Board
- Contact Termination: Crimp
- Gender: Receptacle
- No. of Contacts: 12
- No. of Rows: 2
- Pitch Spacing: 2.54mm
- Withstand Voltage: 600V
- Current Rating: 3A AC/DC
- Voltage Rating: 250V AC/DC
- Max. Contact Resistance: 20mΩ
- Min. Insulation Resistance: 1,000MΩ
- Withstanding Voltage: 1,000V AC/minute
- Temperature Range: -25°C to +125°C
- Application Wires: 28AWG to 24AWG
- Insulator Material: Polyester
- Contact Material: Phosphor Bronze
- Finish: Tin Plated or Gold Plated
- A Dimension: 12.70mm
- B Dimension: 15.24mm
