MULTICOMP-PRO 2AD1T2A2M2RE Sub-Miniature Toggle Switch
The 2AD1T2A2M2RE is a Double Pole Double Throw (DPDT) non-illuminated, through-hole sub-miniature sealed toggle switch. It features an ON-ON switch function with solder terminals, a glass-filled nylon 66 heat-stabilized casing and bushing, chrome-plated brass components, and an internal O-ring seal that ensures reliable sealing for all actuators. The switch offers a minimum insulation resistance of 1000 MΩ, a dielectric strength of 1000 Vrms at sea level, and a mechanical life of 30,000 cycles. It operates within a temperature range of -30°C to 85°C and is suitable for industrial applications.
MULTICOMP-PRO 2AD1T2A2M2RE Sub-Miniature Toggle Switch Specifications:
- Contact Rating: 0.4 Volt-Amps (VA) max. at 20V max. (AC or DC)
- Mechanical Life: 30,000 make-and-break cycles
- Contact Resistance: 20mΩ max. initial at 2 to 4V DC
- Min. Insulation Resistance: 1000 MΩ
- Dielectric Strength: 1000 Vrms at sea level
- Operating Temperature: -30°C to +85°C
- Case and Bushing Material: Glass filled nylon 66, heat stabilized
- Actuator Material: Brass, chrome plated
- Switch Support: Brass or steel, tin plated
- Contacts/Terminals: Copper alloy, with gold plating
Buy the Buy multicomp:ro Sub-Miniature Toggle Switch Part Number 2AD1T2A2M2RE Online
Purchase the multicomp:ro Sub-Miniature Toggle Switch with DPDT ON-ON function today for your industrial or control applications. Featuring a sealed epoxy casing, glass-filled nylon body, chrome-plated brass components, and gold-plated contacts, this switch ensures durability, high insulation resistance, and reliable operation within a temperature range of -30°C to 85°C. With a mechanical lifespan of 30,000 cycles and a maximum contact load of 0.4 VA at 20V, it is ideal for precise switching needs in harsh environments. Buy online now for swift delivery and dependable performance.
Buy multicomp:ro 2AD1T2A2M2RE toggle switch now and experience reliable performance with a sealed, industrial-grade design suitable for control panels.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO 2AD1T2A2M2RE?
You can click on the BUY or RFQ button to purchase 2AD1T2A2M2RE from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part 2AD1T2A2M2RE?
You can download the 2AD1T2A2M2RE datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of 2AD1T2A2M2RE?
MULTICOMP-PRO
