MULTICOMP PRO 3MD4M1QE DPDT Switch
The Multicomp Pro DPDT switch with a long rocker actuator provides reliable switching for industrial control and automation applications. Featuring a silver contact material for excellent conductivity, epoxy sealing for durability, and RoHS compliance, this switch offers a mechanical life of 50,000 cycles, a contact resistance of 10m initially at 2 to 4V DC and 100mA, and a dielectric strength of 1,000 Vrms. It operates in temperatures from -30°C to 85°C, with a body made of diallyl phthalate and a nylon housing, ensuring high performance and longevity in demanding environments.
MULTICOMP PRO 3MD4M1QE DPDT Switch Specifications:
- Contact Rating: 2A resistant load at 120V AC or 28V DC, 250V AC
- Mechanical Life: 50,000 make-and-break cycles
- Max. Contact Resistance: 10m initial at 2 to 4V DC 100mA
- Min. Insulation Resistance: 1,000 MO
- Dielectric Strength: 1,000 Vrms at sea level
- Operating Temperature: -30°C to 85°C
- Materials: Diallyl phthalate (DAP) case, nylon housing, brass nickel plated bushing, stainless steel switch support, brass tin-plated terminals, silver-plated contacts
Buy the Multicomp Series DPDT Switch: 3MD4M1QE
Enhance your control panel with our robust DPDT switch, featuring silver contacts, epoxy sealing, and RoHS compliance. Designed for durability, this switch withstands -30°C to 85°C, offers 50,000 mechanical cycles, and provides reliable conduction with a contact resistance of just 10m. Its high dielectric strength of 1,000 Vrms and high-quality materials ensure long-term performance for industrial, automation, or control systems. Easy to install, it’s the trusted choice for engineers seeking dependable switching solutions for demanding environments.
Order your Multicomp Series DPDT switch 3MD4M1QE today and give your projects the dependable quality they deserve.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 3MD4M1QE?
You can click on the BUY or RFQ button to purchase 3MD4M1QE from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 3MD4M1QE?
You can download the 3MD4M1QE datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 3MD4M1QE?
MULTICOMP PRO
