MULTICOMP-PRO 3MS5M1QE Rocker and Paddle Switch
The switch, SP On-Off-MOM, is a high-quality rocker or paddle switch suitable for various electronic and electrical applications. Made with durable materials such as nylon, brass, and stainless steel, it features silver-plated contacts for reliable conductivity and epoxy sealing for enhanced protection. With a mechanical life of 50,000 cycles, contact resistance of 10mΩ, and insulation resistance of 1000 MΩ, it operates within -30°C to 85°C. The switch is RoHS compliant, with options for panel mounting actuators, solder lug terminations, and different pole configurations, ensuring versatility and reliable performance in control systems and automation setups.
MULTICOMP-PRO 3MS5M1QE Rocker and Paddle Switch Specifications:
- Contact Rating: 2A at 120V AC or 28V DC, 50,000 cycles
- Material: Diallyl phthalate case, nylon housing, brass bushing, stainless steel switch support, tin-plated brass contacts
- Insulation Resistance: 1000 MΩ
- Dielectric Strength: 1000 Vrms at sea level
- Operating Temperature: -30°C to 85°C
- Dimensions: Length 29.36 mm, width 23.8 mm, diameter 0.094 inches, typical actuator length 13.49 mm
- Termination: Solder Lug (0.078 inches thick)
- Seal Type: Epoxy
- RoHS Compliant
- Switch Function: SP On-Off-MOM, DPDT On-None-On, SP On-None-On
- Poles: 3 poles with variety of configurations
- Actuator Options: R1 long rocker, R2 lever for panel mount
- Soldering: Control at 350°C for 5 seconds, wave or vapour phase options with temperature profile
Buy the Buy multicomp Series8 Rocker and Paddle Switch Part Number 3MS5M1QE Online
Purchase the high-quality multicomp Series8 rocker and paddle switch 3MS5M1QE online today. Engineered for reliability, it features epoxy sealing, silver contacts, and robust materials suitable for industrial control systems. Its versatile mounting options, solder lug terminations, and multiple pole configurations make it ideal for automation, machinery, and electronics projects. With excellent resistance ratings, long mechanical life, and RoHS compliance, this switch ensures safety and longevity in demanding environments. Order now and improve your control solutions with our trusted switch.
Order your multicomp Series8 3MS5M1QE rocker switch today and enhance your control panels with dependable, durable switch solutions.
Frequently Asked Questions
Where can I buy MULTICOMP-PRO 3MS5M1QE?
You can click on the BUY or RFQ button to purchase 3MS5M1QE from an authorized MULTICOMP-PRO distributor.
How do I troubleshoot issues or seek technical support for part 3MS5M1QE?
You can download the 3MS5M1QE datasheet or visit the MULTICOMP-PRO website for support.
Who is the manufacturer of 3MS5M1QE?
MULTICOMP-PRO
