MULTICOMP-PRO 4US1R202M2RN Miniature Rocker Switch
The 4US1R202M2RN is a compact and durable subminiature rocker switch designed for industrial automation and electronic control systems. It features a black nylon lever actuator, gold-plated copper alloy contacts for high conductivity, and a heat-stabilized, glass-filled nylon case for resistance to harsh environments. With a contact resistance below 100mΩ and an insulation resistance of 500MΩ, this SPDT switch supports reliable switching operations at temperatures from -30°C to +85°C. Ideal for applications requiring robust performance and minimal size, it is suitable for panel mounting and embedded control panels.
MULTICOMP-PRO 4US1R202M2RN Miniature Rocker Switch Specifications:
- Contact Rating: 0.4 Volt-Amps at 20V AC/DC Max.
- Mechanical Life: 50,000 cycles.
- Contact Resistance: below 100mΩ at 2 to 4V DC, 100mA.
- Insulation Resistance: 500MΩ at 500V DC.
- Dielectric Strength: 500 Vrms at sea level.
- Operating Temperature: -30°C to 85°C.
- Actuator Material: Nylon, black standard.
- Contact Material: Gold-plated copper alloy.
- Seal: Internal O-ring seal standard.
- Switch Function: SPDT, ON-ON.
- Number of Poles: Single pole.
- Construction: PC through-hole terminals, heat-stabilized nylon case.
- Dimensions: Compact size suitable for embedded mounting.
- Certifications: RoHS compliant.
Buy the BrandName 4US1R202M2RN – Reliable SPDT Sub-Miniature Switch for Industrial Applications
Secure your automation projects with the BrandName 4US1R202M2RN miniature switch. Featuring gold-plated contacts, a robust nylon case, and a reliable ON-ON SPDT configuration, this switch is optimized for industrial environments. Easy to install with PC through-hole terminals, it offers a long mechanical life of 50,000 cycles and can operate efficiently across a temperature range of -30°C to +85°C. Order now online for quick delivery and ensure dependable switching in your control panels and electronic systems.
Buy BrandName 4US1R202M2RN now and experience unmatched reliability and performance in your industrial control systems.
