MULTICOMP PRO 698076 D-Sub Connector
The 698076 is a 15-position standard D-sub connector plug designed for reliable signal and power connections. It features gold-plated contacts over nickel for excellent conductivity, a tin-plated solder cup for secure terminations, and a steel shell with tin plating for durability and EMI/RFI shielding. The connector uses PBT and glass fiber reinforced insulators, supports a current of 5A, and withstands voltages up to 500V DC. It offers low contact resistance of 15 milliohms, high insulation resistance of 5,000 megaohms, and dielectric withstand voltage of 1000VAC for one minute, making it ideal for demanding electronic applications.
MULTICOMP PRO 698076 D-Sub Connector Specifications:
- Current Rating: 5 Amps at 25°C
- Insulation Resistance: 5000 megaohms minimum at 500V DC
- Dielectric Withstanding Voltage: AC 1000V minimum (for 1 minute)
- Contact Resistance: 15 milliohms maximum (mated)
- Operating Temperature: -55°C to +105°C
- Insulator Material: PBT and Glass-Fibre reinforced
- Contact Material: Brass, Gold over Nickel, Tin plated solder cup
- Shell Material: Steel, Tin plated
- Working Voltage: 250Vrms
Buy the Multicomp Series D-Sub Connector: 698076
Purchase the Multicomp D-Sub Connector 698076 online today for a reliable, durable solution in electronic assembly. Featuring gold-plated contacts for optimal conductivity, tin-plated solder cups for secure wiring, and steel shells for EMI/RFI shielding, this 15-position connector is rated for 5A and up to 500V DC. Its reinforced insulators ensure long-lasting performance in demanding environments. Easy to install and highly dependable, it’s perfect for industrial, communication, and electronic applications requiring secure signal and power transmission. Order now to experience quality and efficiency!
Get Multicomp Series 698076 today—built for reliable electronic connections with gold-plated contacts and EMI/RFI shielding.
Frequently Asked Questions
Where can I buy MULTICOMP PRO 698076?
You can click on the BUY or RFQ button to purchase 698076 from an authorized MULTICOMP PRO distributor.
How do I troubleshoot issues or seek technical support for part 698076?
You can download the 698076 datasheet or visit the MULTICOMP PRO website for support.
Who is the manufacturer of 698076?
MULTICOMP PRO
